Carriages and Carriage Parts - There are 4 sizes of hook type tine carriages rated by the blade carriage lifting capacity. Hook type tine carriages have been consistent.
The carriage bar spacing utilized for Class 1 is roughly thirteen inches and the Class 1 carriage is rated to hold loads as much as 2000lbs. The Class 2 carriage is rated to hold cargo up to 5,500lbs with carriage bar spacing of sixteen inches. Class III carriages are rated for loads as much as 10,000 lbs. The carriage bar spacing for this particular class is twenty inches. Class IV carriages are rated for cargo up to 15,500 lbs. The carriage bar spacing for this capacity is 25 inches.
Pin mounted tines vary by the amount of offset between the blade and the blade eye. Some makers will vary the carriages for pin type tines. Carriage capacity would be determined by the carriage pin size and by the blade size.
